| Optical | Description |
| Light Source | Visible laser diode 650nm |
| Burst mode | Manual |
| Scanning mode | single line |
| Scanning rate | 300scans/second |
| Resolution | ≥3mil |
| Print of contrast | ≤30% |
| Scan error rate | 1/500million |
| Input Voltage | DC5V |
| Power | 100mA operating |
| Current | 20mA Operating |
| Standby Current | <20uA |
| LUX | 3000-12000Lux |
| Depth of field | 5mm-630mm |
| scanning angle | ±60°±55°±30°(left-right/AF-BF/Turn) |
| Transimission distance | Opening Field about 1.5km ,50-300m indoor |
| Decoding Capacity |
UPC/EAN/JAN ,UPC/EAN with Supplementals,UCC/EAN 128, CODE 39,MSI,CODE 11,CODE 39 FULL ASCII,CODE 39 TriOptic code 128,code 128Full ASCII,Codebar ,code 93,Discrete20f5, IATA,RSSvariants,Codabar,Chinese2of5,Inteleaved2/5 interleaved2of5,china post code and all international 1D code |
| Signal prompting | buzzer ,LED light |
| Dimension | L 102mm x W 68mm x H 96mm |
| Weight | 450g |
| Charge interface | RJ-45 WAN ,1M Length(USB Charge cable ,red lighting is in charging,red light off battery full charge |
| Charge | ≥3hours |
| Housing Material | ABS+PC |
| battery working | 15hours per full charge |
| Temperature | -20°c-50°c(operating) -40°c-60°c(storage) |
| Setting type | Manual (scanning setting code ) |
| Laser safty | EN60825-1,class 1 |
| EMC | EN55022,EN55024 |
| Electrical safty | EN60950-1 |
| IP | IP52 |
| Drops | 3M drops to concrete |
| Certificate | ROHS |
